MVXT thermal camera with radiometric functions, in AISI 316L, 12-24Vdc/24Vac, version IP H264/AVC, 35mm, 640x512, 30Hz, armoured cable 4m, sunshield, -60°C/+65°C. ATEX Ex II 2G Ex db IIC T5 Gb, Ex II 2D Ex tb IIIC T100°C Db, -60°C ≤ Ta ≤ +65°C, IP66/68. IECEx Ex db IIC T5 Gb, Ex tb IIIC T100°C Db, -60°C ≤ Tamb ≤ +65°C, IP66/68. EAC Ex Ex II 2G Ex db IIC T5 Gb, Ex II 2D Ex tb IIIC T100°C Db, Ta -60°C/+65°C, IP66/IP68. INMETRO Ex db IIC T5 Gb, Ex tb IIIC T100°C Db, -60°C ≤ Ta ≤ +65°C, IP66/IP68
